Accuphase AD-60


Accuphase AD-60

( 0 out of 5 )
฿100.00

High- performance phono equalizer amp for playback of analog records.
MC/MM switching is possible on the front panel of the enabled device.
Internal DIP switches control MC input impedance and subsonic filter on/off.

Category: Tag: Brand:

  • Analog Disc Input Board – AD-60

High- performance phono equalizer amp for playback of analog records.

  • MC/MM switching is possible on the front panel of the enabled device.
  • Internal DIP switches control MC input impedance and subsonic filter on/off.
MC (Moving Coil type)
Gain : 66 dB
Input Impedance : 30/100/200/300 ohms (selectable)
MM (Moving Magnet type)
Gain : 40 dB
Input Impedance : 47 kilohms
Subsonic filter : 25 Hz -12 dB/octave
  • GUARANTEED SPECIFICATIONS ( Measured according to IEC 60268-3 ) When attached to the C-2300.
Switch Position Sensitivity S/N ratio (EIA)
MM 2.5 mV 80 dB
MC 0.126 mV 68 dB
  • SUBSONIC FILTER ： 25Hz -12dB / octave

Related Products

Street art salvia irony wolf waistcoat actually lomo meh fap jean.
Mola Mola Lupe
